8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss

Model Number : Distribution box

Type : Fiber optic distribution box

Place of Origin : Zhejiang, China

Brand Name : OEM

Use : Fiber optic manufacture

Warranty Time : 1 year

Material : PC+ABS

Color : Black

Atmospheric Pressure : 70kpa~106kpa

Insertion Loss : ≤0.15dB

Upc Return Loss : ≥50dB

Temperature : -40℃~+85℃

IP : IP65

APC Return Loss : ≥60dB

Supply Ability : 80000 Pint/Pints per Month

MOQ : 500 pieces

Price : $10.00/pieces 500-1999 pieces

Contact Now

Products Description

Description

Pre-terminated Fiber Optic IP65 Optical Termination 48 96 144 288 cores Distribution Box is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, and distribution can be done in this box, and meanwhile, it provides solid protection and management for the FTTx network building.
Specification
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss






Application
· Data transmission
· Telecommunication
· Testing equipment
· WBN
· Optical fiber CATV
· LAN indoor/outdoor



FEATURE
1. Total enclosed structure. 2. Material:PC, wet-proof, water-proof, dust-proof, anti-aging, protection level up to IP65. 3. Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution...etc all in one.
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
Product name
Specification
Unit
Quantity
Remark
Box bottom
PCS
1
Box cover
PCS
1
With a protective membrane on the surface
Drop leaf/adapter panel /PLC splitter panel
SET
1
The color is the same as the box body's
Cable holder
SET
2
Zinc alloy material
Cutting fits
PCS
1
Grounding devices
SET
Sealing part for drop cable
PCS
16
The color is the same as the box body's
Sealing part for box body
PCS
1
Lock
SET
1
PLC splitter
1*8
PCS
2
Optical as the customer's request
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
Details Images
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
8-288 Cores Fiber Optic Splice Closures Distribution Box with 0.15dB Insertion Loss
1. Are you a manufacturer or trade company?

We are the manufacturer with nearly 20 years' history.

2. What is your fiber brand?

Our fiber brands include: YOFC, Corning, Fiber Home, J-fiber, POFC

3. What is your main product?

Our main product is Fiber Optic Connector, Fiber Optic Adapter, Fiber Optic Attenuator, Fiber Optic Patch Cord, and Fiber Terminal
Box, except that, we have very good prices for part of the fiber tools!

4. How can we place order?

After we agreed on the product parameters, we will make proforma invoice for your confirmation, when we got your advance payment
(deposit) we will arrange the production and delivery. If you have your ship forwarder, we will use your ship forwarder to deliver
goods; if you don't have ship forwarder, we can ship them by our agent shipping company which can offer very competitive freight
costs!

5. What is the quality of your product?

All of our products are of high quality, we promise 100% recall policy if they are unqualified, we can write it into our contract!

6. How do you arrange the shipping?

Solution A: FIBCONET takes care of everything. Clients only need to collect cargo in locally or wait for cargo delivery to their
office. There are two types of shipping methods available, by sea and by air (Express courier - FedEx/ DHL/UPS/TNT/EMS, we can
ship them according to your express account or ship them by our agent company, the delivery time is about four days).
Solution B: Clients assign a Shenzhen logistic company to do the shipping, FIBCONET follows the company's instructions and finishes the shipping.

7. How can you guarantee the delivery time?

1To avoid the delay, we have built a complete and professional procedure system from production to delivery and have rich
experience. We can regulate the penalty clause in the contract for the late delay.

8. What's your best price for your passive fiber optic product?

Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the time.

9. What is your quality control for your fiber optic product?

1. Source Guarantee. We have our long-term cooperation with raw material suppliers. All the products are ROHS certificated and
satisfy exporting quality level demand.
2. Quality Test. It runs through the whole process from the raw material to the finished product, such as package, surface,
physical test, and optical test. They are 100% tested.
3. Optical Test. Our products are strictly tested following IEC and ITU standards.
4. We have 30% spot test by Quality Assurance Department after the products are finished.

10. Why choose FIBCONET Fiber Optic to cooperate?

1. We have first-class production line and strict quality management system.
2. We have professional procedure system and big production capacity to guarantee fast delivery and on-time shipment.
3. We can provide the most competitive price to meet your budget.
4. We also design and innovate new products based on our rich experience.
5. We have professional team to provide comprehensive one-stop service for you.

Please always feel free to contact us for any questions, it's our honor to be in service of you Features!
